Parameters

Specification

Voltage

380V/50HZ/3PH or customized

Driving Motor

4 KW

Forming Steps

15 steps

Working Speed

15-18m/min

Thickness for Steel

0.8-1.2mm

Shaft Diameter

65mm

Shaft Material

High grade 45# forged steel

Roller Material

G45# steel, CNC lathe,polished and chrome plated

PLC Cabinet

Schneider, Delta

Encoder

Omron

Sprocket Wheel

45 steel high-frequencies quench

Cut-off System

Post cutting, no waste cutting

Cutting Blade Material

Cr12 steel

Machine Frame Material

Fine welded structural steel;

Raw Material

GI steel G330-550

Painted Color

Blue+Orange Or Customization

Overall Size

7200*950*1050mm

Weight

2500KGS
